Display
|
Panel Size (inch) : 15.6
|
|
Aspect Ratio : 16:9
|
|
Display Viewing Area (H x V) : 344.23*193.54mm
|
|
Display Surface : Non-Glare
|
|
Backlight Type : LED
|
|
Panel Type : TN
|
|
Viewing Angle (CR≧10, H/V) : 90°/ 65°
|
|
Pixel Pitch : 0.252mm
|
|
Resolution : 1366x768 (WXGA )
|
|
Brightness (Typ.) : 220cd/㎡
|
|
Contrast Ratio (Typ.) : 500:1
|
|
Display Colors : 260K
|
|
Response Time : 10ms(Tr+Tf)
|
|
Refresh Rate (Max) : 60Hz
|
|
Flicker-free : No
|
Video Feature
|
HDCP : Yes
|
|
DisplayWidget : Yes
|
Audio Feature
|
Speaker : No
|
I/O Ports
|
USB 3.2 (Signal) : x 1
|
Power Consumption
|
Power Consumption : 4.88 W
|
|
Power Saving Mode : <0.5W
|
|
Power Off Mode : <0.3W
|
|
Voltage : DC: 5V, 3A
|
Mechanical Design
|
Height Adjustment : No
|
|
1/4" Tripod Socket : Yes
|
Dimensions (Esti.)
|
Phys. Dimension without Stand (W x H x D) : 360.14*225.64*11.8mm
|
|
Box Dimension (W x H x D) : 434 x 290 x 76 mm
|
Weight (Esti.)
|
Net Weight without Stand : 780g
|
|
Gross Weight : 1.65 kg
|
