| Model |
CS-H6-R100-1J5WF |
| Image Sensor |
1/2.7" Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Lens |
4mm @ F1.6, View Angle: 87° (Horizontal), 53° (Vertical), 104° (Diagonal) |
| Pan / Tilt Angle |
Pan: 353°, Tilt: 133° |
| Minimum Illumination |
0.51 Lux @ (F1.6, AGC ON); 0 Lux with IR |
| Lens Mount |
M12 |
| Day & Night |
IR-cut filter with auto-switching |
| Digital Noise Reduction |
3D DNR |
| Wide Dynamic Range |
Digital WDR |
| Backlight Compensation |
Supports |
| Night Vision |
Up to 10 m (IR) |
| Max. Resolution |
2880 × 1620 (3K Resolution) |
| Frame Rate |
Max. 25 fps; Self-Adaptive during network transmission |
| Video Compression |
H.265 / H.264 |
| Audio Compression |
Self-Adaptive |
| Max. Bitrate |
4 Mbps |
| Wi-Fi Standard |
IEEE 802.11a / b / g / n / ac |
| Frequency Range |
2.4G: 2400–2483.5 MHz; 5G: 5170–5250 MHz, 5735–5835 MHz |
| Wi-Fi Pairing |
AP pairing |
| Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Network Protocol |
EZVIZ Cloud Proprietary Protocol |
| Wired Network |
RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
| Local Storage |
MicroSD card slot (Max. 512 GB) |
| Cloud Storage |
EZVIZ Cloud Storage |
| Smart Alarm |
AI-Powered Human Shape Detection, Pet Detection, Waving-Hand Detection, Voice Activity Detection |
| Two-Way Talk |
Supports (Dual Microphone) |
| General Functions |
Anti-Flicker, Dual-Stream, Heartbeat, Mirror Image, Password Protection, Watermark |
| Operating Conditions |
-10°C to 45°C (14°F to 113°F), ≤95% Humidity (non-condensing) |
| Power Supply |
DC 5V / 2A (Type-C) |
| Power Consumption |
Max. 8 W |
| Product Dimensions |
115.5 × 116 × 160 mm (4.55 × 4.57 × 6.30 in) |
| Packaging Dimensions |
116 × 116 × 164 mm (4.57 × 4.57 × 6.46 in) |
| Net Weight |
255 g (8.99 oz) |
| Weight (With Package) |
487 g (17.18 oz) |
| In the Box |
H6 Camera, Base, Power Cable, Power Adapter, Drill Template, Screw Kit, Quick Start Guide, Regulatory Information |
| Certifications |
CE / UKCA / UL / WEEE / RoHS / REACH |
