Standards and Protocols
|
IEEE 802.3, 802.3u, 802.3ab, IEEE 802.3x, IEEE 802.1q
|
|
TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP
|
Interface
|
1 Fixed Gigabit WAN Port
|
|
2 Fixed Gigabit LAN Ports
|
|
2 Changeable Gigabit WAN/LAN Ports
|
|
1 USB 2.0 Port (Connecting 4G/3G Modem as WAN Backup‡)
|
Network Media
|
10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
|
|
EIA/TIA-568 100Ω STP (Max 100m)
|
|
100BASE-TX: UTP category 5, 5e cable (Max 100m)
|
|
EIA/TIA-568 100Ω STP (Max 100m)
|
|
1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)
|
Button
|
Reset Button
|
Power Supply
|
External 12V/1A DC Adapter
|
Flash
|
128 MB NAND
|
DRAM
|
256 MB DDR
|
LED
|
PWR, SYS, WAN (Link/Act), LAN (Link/Act), USB
|
Dimensions ( W x D x H )
|
6.2 × 4.0 × 1.0" (158 × 101 × 25mm)
|
Max Power Consumption
|
7.94 Watts
|
Concurrent Session
|
150,000
|
New Sessions /Second
|
2,600
|
NAT (Static IP)
|
Upload: 945.77 Mbps
|
|
Download: 945.56 Mbps
|
|
Bi-Directional: 1808.29 Mbps
|
NAT(DHCP)
|
Upload: 945.93 Mbps
|
|
Download: 945.43 Mbps
|
|
Bi-Directional: 1808.11 Mbps
|
NAT(PPPoE)
|
Upload: 940.44Mbps
|
|
Download: 940.52 Mbps
|
|
Bi-Directional: 1804.27 Mbps
|
NAT (L2TP)
|
Upload: 845.64 Mbps
|
|
Download: 802.65 Mbps
|
|
Bi-Directional: 931.96 Mbps
|
NAT (PPTP)
|
Upload: 771.66 Mbps
|
|
Download: 874.81 Mbps
|
|
Bi-Directional: 999.54 Mbps
|
64 Byte Packet Forwarding Rate
|
Upload/Download: 1,402,238 pps
|
|
Bi-Directional: 1,681,548 pps
|
IPsec VPN Throughput
|
ESP-MD5-AES256: 171.26 Mbps
|
|
ESP-SHA1-AES256: 224.86 Mbps
|
|
ESP-SHA2-AES256: 248.04 Mbps
|
OpenVPN
|
21.70 Mbps
|
L2TP VPN Throughput
|
Unencrypted: 864.65 Mbps
|
|
Encrypted: 47.11 Mbps
|
PPTP VPN Throughput
|
Unencrypted: 703.20 Mbps
|
|
Encrypted: 76.65 Mbps
|
ACL
|
IP/Port/Protocol/Domain Name Filtering
|
Advanced Routing
|
Static Routing
|
|
Policy Routing
|
Bandwidth Control
|
IP-based Bandwidth Control
|
Load Balance
|
Intelligent Load Balance
|
|
Application Optimized Routing
|
|
Link Backup (Timing§, Failover)
|
|
Online Detection
|
NAT
|
One-to-One NAT§
|
|
Multi-Net NAT
|
|
Virtual Server
|
|
Port Triggering§
|
|
NAT-DMZ
|
|
FTP/H.323/SIP/IPSec/PPTP ALG, UPnP
|
Session Limit
|
IP-based Session Limit
|
IPsec VPN
|
20 IPsec VPN Tunnels
|
|
LAN-to-LAN, Client-to-LAN
|
|
Main, Aggressive Negotiation Mode
|
|
DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
|
|
IKEv1/v2
|
|
MD5, SHA1 Authentication Algorithm
|
|
NAT Traversal (NAT-T)
|
|
Dead Peer Detection (DPD)
|
|
Perfect Forward Secrecy (PFS)
|
PPTP VPN
|
PPTP VPN Server
|
