Display
|
Display Size (in.): 22
|
|
|
Viewable Area (in.): 21.5
|
|
|
Panel Type: TN Technology
|
|
|
Resolution: 1920 x 1080
|
|
|
Resolution Type: FHD (Full HD)
|
|
|
Static Contrast Ratio: 600:1 (typ)
|
|
|
Dynamic Contrast Ratio: 50M:1
|
|
|
Light Source: LED
|
|
|
Brightness: 250 cd/m² (typ)
|
|
|
Colors: 16.7M
|
|
|
Color Space Support: 8 bit (6 bit + Hi-FRC)
|
|
|
Aspect Ratio: 16:9
|
|
|
Response Time (Typical Tr+Tf): 5ms
|
|
|
Viewing Angles: 90º horizontal, 65º vertical
|
|
|
Backlight Life (Hours): 30000 Hrs (Min)
|
|
|
Curvature: Flat
|
|
|
Refresh Rate (Hz): 60
|
|
|
Blue Light Filter: Yes
|
|
|
Flicker-Free: Yes
|
|
|
Color Gamut: NTSC: 72% size (Typ)
|
|
|
sRGB: 102% size (Typ)
|
|
|
Pixel Size: 0.248 mm (H) x 0.248 mm (V)
|
|
|
Surface Treatment: Anti-Glare, Hard Coating (3H)
|
|
Compatibility
|
PC Resolution (max): 1920x1080
|
|
|
Mac® Resolution (max): 1920x1080
|
|
|
PC Operating System: Windows 10 certified; macOS tested
|
|
|
Mac® Resolution (min): 1920x1080
|
|
Connector
|
VGA: 1
|
|
|
HDMI 1.4: 1
|
|
|
Power in: DC Socket (Center Positive)
|
|
Power
|
Eco Mode (Conserve): 18W
|
|
|
Eco Mode (optimized): 20W
|
|
|
Consumption (typical): 22W
|
|
|
Consumption (max): 24W
|
|
|
Voltage: HONOR ADS-25SGP-12 12024E 100-240V
|
|
|
Stand-by: 0.3W
|
|
|
Power Supply: External Power Adaptor
|
|
Controls
|
Physical Controls: Auto, -, +, Menu, Power
|
|
|
On Screen Display: Auto Image Adjust, Contrast/Brightness, Input Select, Color Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall
|
|
Operating Conditions
|
Temperature: 32°F to 104°F (0°C to 40°C)
|
|
|
Humidity (non-condensing): 20% to 90%
|
|
Wall Mount
|
VESA Compatible: 75 x 75 mm
|
|
Input Signal
|
Frequency Horizontal: 24 ~ 82KHz
|
|
|
Frequency Vertical: 50 ~ 75Hz
|
|
Video Input
|
Digital Sync: TMDS - HDMI (v1.4)
|
|
|
Analog Sync: Separate - RGB Analog
|
|
Ergonomics
|
Tilt (Forward/Back): -4º / 14º
|
|
Weight (imperial)
|
Net (lbs): 4.6
|
|
|
Net Without Stand (lbs): 4
|
|
|
Gross (lbs): 6.6
|
|
Weight (metric)
|
Net (kg): 2.1
|
|
|
Net Without Stand (kg): 1.8
|
|
|
Gross (kg): 3
|
|
Dimensions (imperial) (wxhxd)
|
Packaging (in.): 22.1 x 14.4 x 4.3
|
|
|
Physical (in.): 20.1 x 14.6 x 7.3
|
|
|
Physical Without Stand (in.): 20.1 x 12.2 x 1
|
|
Dimensions (metric) (wxhxd)
|
Packaging (mm): 562 x 365 x 110
|
|
|
Physical (mm): 510 x 370 x 185
|
|
|
Physical Without Stand (mm): 510 x 310 x 25
|
|
General
|
Regulations: CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, UKCA, PSB, BIS
|
|
|
PACKAGE CONTENTS: VA2223-H x1, HDMI Cable (v1.4; Male-Male) x1, AC/DC Adapter x1, Quick Start Guide x1, Power plug x2
|
|
|
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
|
